| YD13151 离合器部件明细表 Parts List of Clutch KV+K1 | |||
| 位置号 Fig.No. | 零件号(标准号) Part No. (Standard No.) | 名称及规格 Specification | YD13006 |
| 013 | |||
| 012 | YD13351008 | 轴Axle(151) | 1 |
| 040 | 0634313536 | 0型圈0-ring 49×3 | 1 |
| 050 | 0734401106 | 搭扣密封环Sealing ring | 3 |
| 060 | GB/T898-1988 | 螺柱Stud M8×18 | 3 |
| 070 | GB/T6170-2000 | 螺母Nut M8 | 3 |
| 080 | 0769120468 | 调整垫片Regulating shim | 1 |
| 100 | YD13351006 | 齿轮Gear(KV/R)Z=50 | 1 |
| 110 | 0730150774 | 承磨垫Thrust washer DUP | 1 |
| 130 | YD13351007 | 轴承Bearing(WTB35×64 ×38) | 1 |
| 140 | 4642308185 | 承压板Press board | 2 |
| 150 | 4644353051 | 活塞Piston | 1 |
| 155 | 4644353051 | 活塞Piston | 1 |
| 160 | 0750112141 | 异形密封环Special sealing ring | 2 |
| 170 | 4644351094 | 止动片Limit plate | 1 |
| 174 | 4642308555 | 止动片Limit plate | 1 |
| 200 | 0750112140 | 异形密封环Special sealing ring | 2 |
| 220 | 0732041183 | 压力弹簧Pressured spring | 2 |
| 230 | 4642308083 | 导向环Guide ring | 4 |
| 240 | 0630531346 | 挡圈Retaining ring AV55 | 2 |
| 250 | 4642308084 | 导向环Guide ring | 2 |
| 260 | 0750115182 | 滚针轴承Needle bearing 35 ×42×20 | 1 |
| 270 | 0730513610 | 弹性挡圈Flexible retaining ring | 1 |
| 280 | 0635303204 | 滚针轴承Needle bearing | 1 |
| 290 | 0730513611 | 弹性挡圈Flexible retaining ring | 1 |
| 300 | 0769124115 | 弹性挡圈Flexible retaining ring | 2 |
| 310 | 0730150779 | 承磨垫Thrust washer DUP | 1 |
| 320 | YD13351011 | 齿轮Gear(K1)Z=25 | 1 |
| 324 | 0630502037 | 孔用挡圈Retaining ring for hole 75×2.5 | 1 |
| 330 | 0769120556 | 调整垫片Regulating shim | 1 |
| 340 | 0750115109 | 滚针组Needle set | 1 |
| 350 | 4644351029 | 挡圈Retaining ring | 1 |
| 352 | GB/T308-1989 | 钢球Steel ball | 2 |
| 356 | 4642351015 | 圆柱销Straight pin | 2 |
| 358 | GB/T79-2000 | 螺钉Screw M12×20 | 2 |
| 360 | GB/T276-1994 | 球轴承Ball bearing 6009 45×75×16 | 1 |
| 390 | YD13251001 | 离合器组件Clutch assy. | 1 |
| 420 | 0501309329 | 外摩擦片Ex.frictional disc S=2.0 | 13 |
| 432 | 4642308330 | 内摩擦片In.frictional disc s=1.5 | 5 |
| 434 | 4642308332 | 内摩擦片In.frictional disc S=2.0 | 6 |
| 436 | 0769129011 | 内摩擦片In frictional disc S=1.5/2,0/2,5 | 1 |
| 440 | 0501309329 | 外摩擦片Ex.frictional disc D=137.5 S=2,0 | 9 |
| 450 | 4642308330 | 内摩擦片In.frictional disc S=1.5 | 6 |
| 452 | 4642308332 | 内摩擦片In.frictional disc S=2.0 | 1 |
| 456 | 0769129011 | 内摩擦片In.frictional disc S=1.5/2,0/2.5 | 1 |
