| YD13131 加油管部件明细表 Parts List of Oiling Pipe | ||||
| 位置号 Fig.No. | 零件号(标准号) Part No. (Standard No.) | 名称及规格 Specification | YD13006 | 备 注 Remark |
| 010 | 4642231005 | 加油管组件Oiling pipe as- sy. | 1 | |
| 030 | 4642331216 | 纸垫Gasket δ=0.8 | 3 | |
| 040 | GB5783-86 | 螺栓Bolt M8×50 | 2 | |
| 060 | 4644231086 | 油标尺组件Dipstick assy. (A=279) | 1 | |
| 080 | 4642331056 | 挡板Baffle | 1 | |
| 130 | 4644301016 | 盖板Cover plate | 1 | |
| 150 | GB5783-86 | 螺栓Bolt M8×16 | 2 | |
| 160 | 0636305016 | 螺塞Plug screw AM22×1.5 | 1 | |
| 170 | JB/T982-1977 | 组合密封圈Composition washer 22 | 1 | |
