YD13130 Parts List of Engine Connection
| YD13130 发动机连接部件明细表 Parts List of Engine Connection | ||||
| 位置号 Fig.No. | 零件号(标准号) Part No. (Standard No.) | 名称及规格 Specification | YD13006 | 备 注 Remark |
| 010 | YD13330004 | 连接外壳Connection casing SAE2 | 1 | |
| 030 | GB5783-1986 | 螺栓Bolt M10×35 DIN933 10.9 | 12 | GB5783-86 |
| 040 | 0631329163 | 弹性园柱销Pin 10×28 DIN1481 | 2 | GB879-86 |
| 044 | 0631329069 | 弹性园柱销Pin 6×30 DIN1484 | 2 | GB879-86 |
| 050 | YD13330003 | 盖Cover | 1 | |
| 052 | YD13330006 | 纸垫Gasket | 1 | |
| 054 | GB5783-1986 | 螺栓Bolt M6×10 | 4 | |
| 070 | 4644330849 H | 膜片组件Diaphragm | 2 | |
| 080 | 0636015280 | 螺栓Bolt M10×18 DIN933 10.9 | 4 | GB5783-86 |
| 100 | 0636015120 | 螺栓Bolt M10×25 DIN933 8.8 | 12 | GB5783-86 |
| 150 | 4166330858 | 罩法兰Casing flange | 1 | |
| 154 | 4166330232 | 纸垫Gasket | 1 | |
| 260 | 4166330123 | 垫圈Washer | 1 | |
| 270 | 0634313260 | 0型圈0-ring 25×3 ZFN744 | 1 | |
| 280 | 0630502015 | 孔用挡圈Retaining ring 30 x1.2 DIN472 | 1 | GB894.1-86 |
