YD13121 Parts List of Suction Pipe
| YD13121 吸油管部件明细表 Parts List of Suction Pipe | ||||
| 位置号 Fig.No. | 零件号(标准号) Part No. (Standard No.) | 名称及规格 Specification | YD13006 | 备 注 Remark |
| 010 | YD13221001 | 吸油管组件Suction pipe assy. | 1 | 组合件Group unit |
| 020 | 4644221821 | 吸油滤组件Suction filter assy. | 1 | 组合件Group unit |
| 030 | 4644321244 | 纸垫Gasket | 2 | |
| 050 | GB/T5782-2000 | 螺栓Bolt M8×50 | 4 | |
| 070 | Q20-03 | 垫圈Washer 16 | 20 | |
| 080 | 0501204427 | 软管Hose tube L=516/2, φ16 | 1 | KV |
| 100 | 0501204673 | 软管Hose tube L=530/2, φ16 | 1 | KR |
| 110 | 0501204523 | 软管Hose tube L=818/1, φ16/1,M18×1,5 | 1 | K1 |
| 120 | 0501204422 | 软管Hose tube L=525/1, φ16/1,M18×1,5 | 1 | K2 |
| 130 | 0501204427 | 软管Hose tube L=516/2, φ16 | 1 | K3 |
| 140 | 0501204427 | 软管Hose tube L=516/2, φ16 | 1 | K4 |
| 170 | 0637842509 | 管接头Adaptor M18/16× 1.5 | 4 | |
| 250 | 0737835153 | 空心螺栓Hollow bolt M16 ×1.5 | 8 | |
| 700 | YD13221002 | 吸油管Suction tube M22 | 1 | |
| 710 | Q21-18 | 空心螺栓Hollow bolt M22 x1.5 | 2 | |
| 714 | Q20-03 | 垫圈Washer 22 | 4 | |
| 720 | YD13221003 | 吸油管Suction tube M14 | 1 | |
| 730 | Q21-19 | 空心螺栓Hollow bolt M14 x1.5 | 2 | |
| 734 | Q20-03 | 垫圈Washer 14 | 4 | |
| 750 | 0636305007 | 螺塞Plug screw AM14×1.5 | 1 | |
| 760 | Q20-03 | 垫圈Washer 14 | 1 | |
