YD13108 Parts List of Idle Wheel
| YD13108 惰轮部件明细表 Parts List of Idle Wheel | ||||
| 位置号 Fig.No. | 零件号(标准号) Part No. (Standard No.) | 名称及规格 Specification | YD13006 | 备 注 Remark |
| 010 | YD13308003 | 惰轮轴Idle wheel shaft | 1 | |
| 020 | 0634313529 | 0型圈O-ring 57×3 | 1 | |
| 050 | 4644308542 | 止推垫片Thrust shim | 1 | |
| 080 | GB/T119.2-2000 | 销Pin A4×10 | 1 | |
| 090 | YD13308001 | 惰轮Idle wheel Z=34 | 1 | |
| 100 | GB/T5783-2000 | 螺栓Bolt M8×20 | 4 | |
| 110 | YD13308002 | 滚子组Roller group | 1 | |
| 140 | GB/T97.2-1985 | 垫圈Washer 10200HV | 1 | |
| 150 | 0501308832 | 挡圈Retaining ring | 1 | |
| 170 | GB/T5783-2000 | 螺栓Bolt M10×20 | 1 | |
