YD13103 Parts List of Output Assembly
| YD13103 输出部件明细表 Parts List of Output Assembly | |||
| 位置号 Fig.No. | 零件号 Part No. (Standard No.) | 名称及规格 Specification | YD13006 |
| 010 | YD13303001 | 输出轴Output shaf | 1 |
| 020 | YD13303003 | 输出齿轮0utput gear Z= 53 | 1 |
| 030 | GB/T283-1994 | 滚柱轴承Roller bearing NJ213E 65×120×23 | 1 |
| 034 | 1204308062 | 调整垫片Regulating shim | 1 |
| 040 | 4620303247 | 压板Press plate | 2 |
| 050 | GB/T5783-2000 | 螺栓Bolt M10×30 | 4 |
| 060 | 1269302164 | 螺栓锁片Bolt retainer | 2 |
| 070 | 0750111116 | 轴用密封圈Sealing ring for shaft WTB,90×120×13 | 2 |
| 080 | GB/T276-1994 | 球轴承Ball bearing 631155 x120×29 | 1 |
| 090 | 0630502048 | 孔用挡圈Retaining ring for hole 120×4 | 3 |
| 100 | 0769120338 | 调整垫片Regulating shim | 1 |
| 110 | 0730062296 | 轴套Sleeve L=20 | 1 |
| 140 | YD13303006 | 输出法兰(SAE 7C)Output flange | 1 |
